The Symbol LS9203 is an omni-directional presentation scanner with durable design, plug‑and‑play setup, and extensive barcode support.
The LS9203 scanner provides both handheld and hands‑free operation, allowing POS staff to quickly capture barcodes in a high‑traffic environment. Its rugged construction includes an internal shock‑absorbing seat and a mounting bracket, enabling it to survive repeated drops onto concrete.
The device features a 650 nm visible laser, up to 1500 scans per second, and supports a wide range of symbologies such as UPC/EAN, Code 128, Code 39, and Interleaved 2 of 5. It operates from a 5 VDC supply (275 mA) and includes a comprehensive two‑year warranty and optional service plans. This manual is written in Chinese.
| Dimensions (without stand) | 5.51 in H × 3.49 in W × 2.96 in D |
|---|---|
| Weight (scanner only) | 9.9 oz (282 g) |
| Power supply | 5.0 VDC ±10%, 275 mA (1.4 W) |
| Laser wavelength | 650 nm visible laser diode |
| Scan rate | 1500 scans per second |
It runs from a 5.0 VDC supply with a current draw of 275 mA (about 1.4 W).
The scanner can capture up to 1500 scans per second.
Symbol offers a two‑year warranty covering defects in materials and workmanship.
Yes, it supports both handheld and hands‑free (presentation) modes for flexible scanning.
