This manual provides system description, configuration, technical specifications, and installation guidelines for the Siemens 6SE70 Vector Control drive.
The SIMOVERT MASTERDRIVES Vector Control system is a three‑phase AC drive with voltage‑source inverter speed control. It supports single‑motor and multi‑motor applications ranging from 0.55 kW up to 2300 kW and operates on input voltages from 380 V to 690 V. The manual covers the enhanced book‑type units, cabinet‑type units, and the 6SE71 variant, as well as hardware and software options.
The document includes detailed sections on system overview, design guidelines, installation procedures, operation and monitoring, open‑loop and closed‑loop control, communication interfaces, and optional expansion boards. Technical support contact information and service center addresses across China are also provided. This manual is written in Chinese.
| Power range | 0.55 kW to 2300 kW |
|---|---|
| Input voltage | 380 V to 690 V |
| Power range (alternative range) | 0.55 kW to 18.5 kW |
The 6SE70 drive supports power ratings from 0.55 kW up to 2300 kW.
It can operate on input voltages of 380 V, 500 V, or 690 V.
Technical support can be reached at Beijing: (010) 6471 9990/800‑810‑4288.
