This manual provides information on the installation, functions, operation, and technical design of the SIMATIC operator units TP 170A, TP 170B, and OP 170B.
This manual covers the Siemens SIMATIC HMI Touch Panels TP 170A, TP 170B and the Operator Panel OP 170B. It is intended for qualified users, system integrators and service engineers who need to install, set up, operate and maintain these devices.
The document is organized into sections on safety guidelines, device features, screen objects, configuration (recipes), system settings, mechanical and electrical installation, software updates, maintenance, and appendices such as technical data, interface assignments and a glossary. This manual is written in Chinese.
| Model | TP 170A, TP 170B, OP 170B |
|---|---|
| Order number | 6AV6591-1DC11-2AB0 |
Installation and operation may only be performed by qualified personnel authorized to work according to safety engineering standards.
The recipe sections describe configuration data for the TP 170B and OP 170B panels, allowing users to set up screen objects and system parameters.
