Sanken Samco-S06 Variable Frequency Drive Instruction Manual

About this manual

The Samco‑S06 series from Sanken offers high‑performance vector control VFDs ranging from 1.5 kW to 75 kW. The drives feature a 32‑bit CPU, built‑in PID pressure control, dual relays, and optional PG sensor modules for precise speed and torque control.

This manual includes technical specifications, wiring diagrams, communication settings (RS485, Modbus‑RTU, Sanken protocol), protection functions, environmental limits, and installation guidelines for various industrial applications such as textile, metal drawing, water supply and more. This manual is written in Chinese.

What's inside

• Series Overview
• Technical Specifications
• Industry Applications
• Wiring Diagram
• Communication Features
• Control Modes
• Protection Functions
• Environmental Requirements
• Installation Guidelines
• Operation Panel

Specifications

Frequently asked questions

What communication protocols does the Samco‑S06 support?

It supports the SANKEN protocol and Modbus‑RTU over an RS485 two‑wire bus.

How many devices can be connected on the RS485 bus?

Up to 32 devices can be directly connected, or up to 247 devices with repeaters.

What is the overload current rating for the 7.5 kW model?

The overload current is rated at 150 % of the rated current for 1 minute.
