This manual introduces the application notice of CCFL-Inverter.
The document outlines safety precautions for handling high‑voltage CCFL inverters, including warnings against touching live parts, storing in dusty or corrosive environments, and using the devices in high temperature or humidity conditions. It also notes the need for additional protection circuits in certain applications such as medical equipment or transportation vehicles.
Technical data includes standard specifications for lamp electrodes, output power options, voltage ratings, and environmental limits. Selection guides list compatible lamp lengths, output power per lamp, and recommended operating conditions for various LCD monitor sizes.
| Electrode length | 6 mm (W6) |
|---|---|
| Electrode length | 4 mm (N4) |
| Electrode length | 8 mm (N8) |
| Output power (2 lamps) | 4.7 W |
| Operating temperature range | ‑40 °C to 85 °C |
| Storage temperature range | ‑40 °C to 85 °C |
| Maximum humidity | 85 % RH |
Yes, the inverter includes a built‑in dimming control circuit that can be driven by an external PWM signal.
