Renesas E100 Installation Guide

About this manual

The Renesas E100 Installation Guide provides step‑by‑step instructions for assembling the simulator, connecting the AC adapter, USB cable, and MCU device, and installing the required debugging software. It also outlines safety checks such as confirming indicator lights and ensuring power is off before making connections.

Key procedures include verifying the contents of the packing list, attaching the MCU to the internal rail, connecting the power and USB cables, installing the simulation software from the supplied CD‑ROM, and optionally linking a user system. The guide notes that the E100 can operate without a user system and provides troubleshooting tips for indicator lights and connection status. This manual is written in Chinese.

What's inside

• Package Contents Verification
• MCU Connection
• Power and USB Cable Connections
• Software Installation
• User System Connection
• Indicator Light Status

Specifications

Frequently asked questions

How should the USB cable be connected?

Connect the supplied USB cable between the E100 simulator and the host computer.

What does the SAFE indicator light indicate?

When the SAFE indicator flashes, it means the USB cable is correctly connected to the host.

Can the E100 be used without a user system?

Yes, the E100 can operate without a user system; in that case do not connect the conversion board to the simulator.
