The Spotlight TM400 FT‑IR and 400N FT‑NIR system delivers high‑resolution, large‑area infrared imaging with flexible sampling modes and advanced software.
The Spotlight TM400 FT‑IR and 400N FT‑NIR system is a laboratory‑grade infrared imaging instrument that offers ultra‑high spatial resolution, a wide sampling range and rapid data acquisition. Users can switch among transmission, reflection, ATR and other imaging modes to obtain high‑quality spectra across large sample areas.
The platform includes a line‑array detector with 16 MCT units, optional InGaAs detector for NIR, and Spectrum Image software that automates data collection, analysis and template‑based multi‑sample testing, enabling unattended overnight runs and fast turnaround for material, pharmaceutical and biomedical applications. This manual is written in Chinese.
| Pixel size options | 1.56 µm, 50 µm |
|---|---|
| Maximum single‑scan sample area | 400 × 400 µm (up to 1200 × 1200 µm) |
| Line‑array detector units | 16 MCT detector units |
| Spectral coverage (low‑frequency limit) | down to 720 cm⁻¹ |
| ATR sample diameter capability | 500 µm (up to 1200 µm) |
It supports transmission, reflection, ATR and additional modes that can be switched at any time.
A single scan can cover up to 400 × 400 µm, with a maximum of 1200 × 1200 µm.
The line‑array detector contains 16 MCT detector units.
