The Pelco high‑speed PTZ camera manual provides safety guidelines, installation steps, configuration settings, and technical specifications.
This manual describes the Pelco high‑speed PTZ camera, a digital signal processing (DSP) camera with integrated zoom lens, pan‑tilt‑zoom (PTZ) unit, and advanced monitoring features. It includes safety precautions, installation preparation, wiring, dip‑switch configuration, and basic operation such as tracking, zoom, and preset positions.
The document also covers OSD menu functions, automatic temperature control, PELCO_D/P protocol operation, and appendices on lightning protection, cleaning, RS‑485 bus basics, address tables, and troubleshooting procedures. This manual is written in Chinese.
| Power consumption | ≤20W |
|---|---|
| Supply voltage | 15V ~ 28V |
| Operating temperature (indoor) | 0°C~+40°C |
| Operating temperature (outdoor) | -40°C~+60°C |
| Maximum humidity | ≤95% |
| Supported communication protocols | PELCO_D, PELCO_P, 3D |
| Baud rates | 1200, 2400, 4800, 9600 bps |
| Horizontal rotation speed | 1~220°/s |
| Number of preset positions | 220 |
Transport the camera in split packaging, avoid heavy pressure, strong vibration, or immersion; damage caused by improper packaging is not covered under warranty.
Use dip‑switch SW2 bits 4‑5 to select 1200, 2400, 4800, or 9600 bps; the factory default is 2400 bps.
The camera consumes no more than 20 W.
Up to 220 preset positions can be stored.
