The NORAC UC7 Boom Height Control System Manual provides safety guidelines, specifications, setup, operation, firmware updates, and maintenance instructions.
The UC7™ Boom Height Control system improves spraying height accuracy and protects the boom under varied field conditions. This manual explains the system’s purpose, key features, and safety precautions for operators and service personnel.
It covers technical specifications, menu navigation, sensor and valve setup, firmware update procedures, routine maintenance tasks, product registration, and support contact information, helping users install, operate, and maintain the system safely and effectively.
| Supply Voltage (rated) | 12VDC |
|---|---|
| Supply Current (rated) | 10A |
| Hydraulic Pressure (maximum) | 3300 psi |
| Baud Rate | 250 kbps |
| Operating Temperature Range | 0°C to 80°C |
Grease the friction pads on the sprayer boom as part of the daily maintenance routine.
The replacement fuse part number is NORAC 106676, corresponding to Littelfuse part –0287010.PXCN.
