The MOONS SS Step-Servo third‑generation step‑servo manual provides features, system configuration, wiring diagrams, software tools and specifications.
The SS Step-Servo is a third‑generation step‑servo that integrates a built‑in motion controller, bus control, multi‑axis networking and a high‑efficiency motor. It offers high precision, low vibration, low noise and low heat generation while supporting various control modes and communication protocols.
This manual describes the product’s key features, software utilities, system configuration options, wiring and connector details, technical specifications, naming conventions and optional accessories. It also includes information on communication interfaces such as RS‑232, RS‑485, Modbus/RTU and CANopen. This manual is written in Chinese.
| Continuous output current (SS03) | 3 A |
|---|---|
| Continuous output current (SS05) | 5 A |
| Input voltage range | 24‑75 V DC |
| Maximum pulse frequency | 2 MHz |
| Operating temperature | 0‑40 °C |
It supports RS‑232, RS‑485 (optional), Modbus/RTU (optional) and CANopen (optional).
Up to 32 axes can be controlled simultaneously.
The SS05 model provides a maximum continuous output current of 5 A.
