The Moons Q‑Programmer manual explains installation, configuration and operation of the Q‑Programmer for MSST series devices.
This manual provides step‑by‑step instructions for setting up the Q‑Programmer hardware, connecting it to RS‑232, RS‑485 or USB interfaces, and configuring I/O pins. It also describes the command set used to program MSST5‑Q, MSST10‑Q, MSST5‑I, MSST10‑I, MSSTAC6‑Q, MSSTAC6‑I and STM23Q devices.
The document includes detailed information on queue commands, segment handling, data transfer modes, and troubleshooting tips, allowing users to efficiently program and test their target devices. This manual is written in Chinese.
| Interface | USB to RS‑485 |
|---|---|
| RS‑485 adaptor bit | Bit4 – RS‑485 adaptor |
| I/O pin Bit0 function | SCL |
| RS‑232 termination | 150 Ω |
Use the Queue Goto command to jump to the desired program segment.
The device provides an RS‑485 adaptor (Bit4) and can be connected via a USB‑to‑RS‑485 cable.
