This Chinese datasheet details the architecture, features, electrical characteristics, and pinouts of the Microchip PIC10F200/202/204/206 family of 8-bit…
This document is a technical datasheet for the PIC10F200/202/204/206 family of high-performance RISC 8-bit flash microcontrollers manufactured by Microchip Technology Inc. The text provides comprehensive information on device architecture, including CPU features, memory organization, and peripheral modules such as Timer0 and comparators.
The datasheet covers specific variations within the product line, distinguishing between the PIC10F200/202 models which lack a comparator module and the PIC10F204/206 models which include an internal absolute reference voltage comparator. It also details electrical specifications, operating conditions, package information (SOT-23, PDIP, DFN), and development support tools. This manual is written in Chinese.
| Operating Voltage Range | 2.0V to 5.5V |
|---|---|
| Maximum Operating Frequency | 4 MHz |
| Flash Endurance | > 100,000 erase/write cycles |
| Data Retention Time | > 40 years |
| Supply Current (Typical) | < 175 µA @ 2V, 4MHz |
| Standby Current (Typical) | 100 nA @ 2V |
The devices operate with a wide voltage range from 2.0V to 5.5V.
The maximum instruction cycle time is 1µs, corresponding to a 4 MHz internal clock.
