This user manual explains features, interfaces, hardware details, electrical specifications, and component selection for Microchip's 10‑24 V dual/single…
The guide provides all the information needed to use the Microchip 10‑24 V Dual/Single Motor Control Driver Board, including an overview of its capabilities and safety notices. It also points users to Microchip's website for the latest documentation and support resources.
The document is organized into chapters covering the board’s interfaces, hardware description, schematic and layout, electrical specifications, and detailed component selection guidelines. Appendices contain full schematics, wiring diagrams, and tables of resistor values for the brake‑enable circuitry. This manual is written in Chinese.
| DC bus high‑threshold voltage (VDCLH) | 27.5 V |
|---|---|
| DC bus low‑threshold voltage (VDCHL) | 23.5 V |
| Comparator supply voltage | 3.3 V |
| Voltage‑divider ratio | 11 |
| Resistor R2 (3.3 V case) | 18 kΩ |
Fill out the warranty registration card and mail it promptly so you can receive product update information.
Visit the Microchip website at www.microchip.com for the most recent documents and software releases.
