User manual for Maxim's HFAN-9.5.0 software that creates and converts test code patterns on Windows PCs.
The HFAN-9.5.0 software provides three main functions: a code pattern creator, a code pattern converter, and additional resources. It runs on Windows desktop computers (Windows 98 or later) with a screen resolution of at least 800 × 600 and is used to generate, edit, and convert complex, non‑standard test patterns for fiber, video, back‑plane and other applications.
The manual describes how to create patterns (PRBS, K28.5, CID, binary text files, mixed patterns), important usage notes (file size limits, pattern granularity), and step‑by‑step examples for both creation and conversion to HEX, PTRN, or DAT formats. It also includes resource links and support contact information. This manual is written in Chinese.
| Supported Operating System | Windows 98 or later |
|---|---|
| Minimum Screen Resolution | 800 × 600 |
| Maximum Pattern Length | 34 million bits |
| Recommended Maximum for Fast Conversion | 2 million bits |
The software runs on Windows 98 or any later Windows version.
The software does not support patterns longer than 34 million bits.
Click the K28.5 button and choose whether to invert the sequence.
