The MAX3171 and MAX3173 are three‑driver/three‑receiver multiprotocol transceivers that operate from a single +3.3 V supply. They support V.28 (RS‑232) and V.10/V.11 (RS‑449, V.36, EIA‑530, EIA‑530‑A, X.21, RS‑423) protocols and can be configured as DTE or DCE interfaces via software‑selectable pins.
The devices are offered in a small 28‑pin SSOP package, feature a no‑cable mode with 2 mA supply current, and include fault‑protected transmitter outputs, thermal‑shutdown protection, and optional deglitching on the MAX3171.
| Supported Protocols | V.28 (RS‑232) and V.10/V.11 (RS‑449, V.36, EIA‑530, EIA‑530‑A, X.21, RS‑423) |
|---|---|
| Package Type | 28‑pin SSOP |
| Storage Temperature Range | -65 °C to +150 °C |
| No‑Cable Mode Supply Current | 2 mA |
| Maximum Supply Voltage Difference | 13 V |
It supports V.28 (RS‑232) and V.10/V.11 (RS‑449, V.36, EIA‑530, EIA‑530‑A, X.21, RS‑423).
In no‑cable mode the supply current drops to 2 mA.
The MAX3173 is offered in a small 28‑pin SSOP package.
