This document is a application note of MAX8570ELT+T,MAX8570EUT+T,MAX8571EUT+T chips
This document provides detailed information on the Maxim MAX8570 series of DC‑DC converters, including the MAX8570, MAX8571, MAX8572, MAX8573, MAX8574, and MAX8575 devices. It describes absolute maximum ratings, electrical characteristics, and typical performance graphs.
The datasheet also includes package information, pin configurations, and application notes such as current‑limit settings and shutdown behavior. All specifications are presented with typical values measured at a junction temperature of 25 °C. This manual is written in Chinese.
| MAX8570 Output Current Limit | 110 mA |
|---|---|
| MAX8574 Output Current Limit | 500 mA |
| SHDN Low Level (VIL) | 2.7 V |
The MAX8574 can deliver up to 500 mA of output current.
The shutdown low‑level voltage is 2.7 V.
