The KND K series servo motor manual provides specifications, wiring diagrams, and selection guidelines for various motor models.
This manual from 北京凯恩帝数控技术有限责任公司 presents the specifications, wiring options, and selection criteria for its K, ST, ZJY‑K and ZJY‑F series servo motors. It includes motor features, dimensional data, connector types, and recommended driver pairings.
Key sections detail motor characteristics such as high‑resolution 23‑bit absolute encoders, IP67 protection, and overload capabilities up to 300 % of rated torque. Tables list rated power, torque, speed, current, and physical dimensions for each model series, helping users choose the appropriate motor for CNC machine tools and automation applications. This manual is written in Chinese.
| Rated power (KA80) | 0.75 kW |
|---|---|
| Rated torque (KA80) | 2.4 N·m |
| Rated speed (KA80) | 3000 rpm |
| Protection rating (KA80) | IP67 |
| Recommended driver (KA80) | SD310‑20 (3× overload) |
The K series motors have an IP67 protection rating.
The manual recommends the SD310‑20 driver, which can achieve a 3‑times overload capacity.
