The Keysight InfiniiVision DSOX1204A/G oscilloscope user manual explains setup, operation, measurement, trigger, waveform generation and other features.
This guide introduces the Keysight InfiniiVision DSOX1204A/G 4‑channel oscilloscope, covering its 70 MHz bandwidth (upgradeable), 2 GSa/s sampling, built‑in measurement functions, serial‑bus decoding and optional waveform generator. It also describes the front‑panel controls, display settings and connectivity options such as USB and LAN.
The manual provides step‑by‑step instructions for powering on the instrument, configuring horizontal and vertical controls, using triggers, acquiring data, performing measurements, saving or printing waveforms, and accessing the built‑in online help and web interface. This manual is written in Chinese.
| Bandwidth | 70 MHz (upgradeable) |
|---|---|
| Maximum sampling rate | 2 GSa/s (interleaved), 1 GSa/s (non‑interleaved) |
| Memory depth | 1 Mpts |
| Waveform generator | Optional, up to 20 MHz |
| Upgrade option | D1200BW1A upgrades bandwidth to 100 MHz |
The base bandwidth is 70 MHz, which can be upgraded to 100 MHz or 200 MHz with optional modules.
Press and hold any key on the front panel to display the online help system.
The scope supports I2C, UART/RS232, CAN, LIN and SPI decoding/triggering.
