The Keysight 8163A/B, 8164A/B, and 8166A/B User Guide provides safety, operation, measurement, and configuration instructions for these Lightwave instruments.
This guide covers the complete setup and use of the Keysight 8163A/B Lightwave Multimeter, 8164A/B Lightwave Measurement System, and 8166A/B Lightwave Multichannel System. It includes safety considerations, hardware specifications, power measurement methods, laser source handling, tunable laser operation, and return‑loss measurement procedures.
The document also details system utilities such as backlight adjustment, GPIB and LAN configuration, module updates, and application software for logging, stability, and PACT analysis. Installation, maintenance, and regulatory compliance information are provided in the later sections.
| Display resolution (Power Meters) | 0.0001 dB/dBm |
|---|---|
| Power input | 100‑240 V ±10%, 48‑66 Hz, 100 VA max |
| Dimensions | 88 mm × 213 mm × 380 mm |
| Net weight | 4.200 kg (9.3 lb) |
| Number of modules supported | 2 |
Use the procedure described in the "How to Change the Value of a Parameter" section to modify a parameter and accept the new value.
The guide defines safety symbols in the "Safety Symbols" section, indicating hazards such as cautions and warnings.
Select the "How to Set the Wavelength" menu option and follow the on‑screen prompts to enter the desired wavelength.
