Industrial Sewing Machine Servo Controller PMX-60 User Manual

About this manual

The document is a user manual for the Industrial Sewing Machine Servo Controller model PMX-60. It outlines safety precautions, product features such as flexible motor/controller configuration and high efficiency, and installation procedures for both hanging and direct-drive motors.

The guide details electrical connections including grounding requirements and power supply configurations (AC 220V or derived from 380V). It defines controller interfaces for the control box, sensor components, and operation panels. Additionally, it lists specific fault codes with their meanings and recommended resolution steps. This manual is written in Chinese.

What's inside

• Safety Instructions
• Product Overview
• Installation Diagrams
• Wiring and Grounding
• Controller Interface Definitions
• Troubleshooting

Frequently asked questions

What is the maximum motor speed for this controller?

The maximum motor speeds are 5000 r/min and 3000 r/min depending on the configuration.

What is the required power supply voltage?

The system requires an AC input of (220±44)V at 50/60Hz.

What is the output power rating?

The controller has an output power of 550W.
