Parameter manual for the i70M series servo motor, covering safety, installation, wiring, and troubleshooting.
This manual provides detailed information for the i70M series AC servo motor and its control box, including safety precautions, installation steps, wiring diagrams, and LED display functions. It also contains the required RoHS and hazardous substance declarations for compliance with EU and Chinese regulations.
The document guides users through proper motor mounting, control box installation, grounding, and adjustment procedures, and includes a common parameters table, fault codes with remedies, and pin‑function diagrams for the control box connectors. This manual is written in Chinese.
| Operating voltage tolerance | ±10 % of the rated voltage |
|---|---|
| Maximum ambient temperature | 45 °C |
| Minimum ambient temperature | 5 °C |
| Warranty period | 18 months |
| Lead content in PCB process | < 800 ppm |
No. When the control box is rated for AC 220 V, it must not be plugged into an AC 380 V outlet, otherwise an error code will appear and the board may be damaged.
The system is guaranteed for 18 months from the date of shipment under normal operating conditions.
