Technical datasheet for the Gowin GW1NR series FPGA covering features, architecture, electrical specs and ordering information.
This datasheet provides a detailed overview of the GW1NR series FPGA products, including their features, architecture, memory options, and configurable function units. It also lists the AC/DC characteristics, timing specifications for the configuration interface, and ordering information to help designers select the appropriate device.
The document includes package and pinout details, part naming conventions, and temperature ratings for both industrial and commercial grades. Related user guides and programming manuals are referenced for further development support.
| Core Supply Voltage (LV) | 1.2 V |
|---|---|
| Maximum Temperature (Industrial Grade) | 100 °C |
| Maximum Temperature (Commercial Grade) | 85 °C |
It describes the features, product resources, architecture, AC/DC characteristics, timing specifications, and ordering information for the GW1NR series FPGA.
Related user guides are available on the Gowin website at www.gowinsemi.com.
