The MPC8568E PowerQUICC™ III family is designed for broadband access equipment such as 3G/WiMAX/LTE base stations, gateways and ATM/TDM/IP devices. It combines a high‑performance e500 core with a flexible communications engine and high‑speed system interfaces, enabling many functions to be integrated on a single chip.
Key features include a 512 KB L2 cache, integrated DDR/DDR2 memory controller with ECC, two triple‑speed Ethernet controllers, a security engine supporting numerous encryption algorithms, and high‑speed interconnects like PCI Express and Serial RapidIO. The processor is offered in a 1023‑pin FC‑BGA package.
| Core frequency | up to 1.33 GHz |
|---|---|
| L2 cache | 512 KB |
| Memory controller | Integrated DDR/DDR2 |
| Ethernet controllers | Two triple‑speed Ethernet controllers |
| Security engine algorithms | DES, 3DES, MD‑5, SHA‑1/2, AES, RSA, RNG, Kasumi, ARC‑4 |
| Package type | 1023‑pin FC‑BGA |
The e500 core can scale up to 1.33 GHz.
It includes a 512 KB L2 cache.
It supports DES, 3DES, MD‑5, SHA‑1/2, AES, RSA, RNG, Kasumi, and ARC‑4.
The processor is available in a 1023‑pin FC‑BGA package.
