A comprehensive data book from Fairchild covering memory and high‑speed logic devices such as ECL, TTL, and MOS RAMs, PROMs and programmable logic.
The Fairchild Memory and High Speed Logic Data Book provides product indexes, selection guides, cross‑references and detailed electrical specifications for a wide range of semiconductor devices. It includes sections on ECL RAMs, TTL RAMs, MOS static RAMs, various PROM families and programmable logic arrays.
In addition to technical data, the book contains quality‑assurance procedures, package outlines and a directory of Fairchild sales offices worldwide, helping designers and engineers locate the right part and obtain support.
| VOH Output HIGH Voltage | -1.02 to -0.87 V |
|---|---|
| VOL Output LOW Voltage | -1.81 to -1.60 V |
| VIH Input HIGH Voltage | -1.15 to -0.88 V |
| VIL Input LOW Voltage | -1.81 to -1.48 V |
Fairchild maintains sales offices in the United States, Canada, Europe, Asia and other regions; for example, the Alabama Huntsville office is at 555 Sparkman Drive.
The F100K family guarantees an output high voltage (VOH) between -1.02 V and -0.87 V.
