A selector guide for Dialight Prism CBI and Micro LED SMD LED indicators, covering specifications, package options, and applications for 591, 592, 593, and…
This document serves as a selector guide for Dialight's Prism CBI and Micro LED SMD LED product lines. It details the features and benefits of the Prism CBI series, which includes single, bi-level, and tri-level configurations designed for limited-space applications and board-edge mounting. The guide highlights compatibility with automatic pick-and-place equipment and RoHS compliance.
| Reflow Temperature | 260°C peak |
|---|---|
| Low Current Option | 2mA |
| RoHS Compliance | Compliant |
| Package Sizes (Micro LED) | 0603, 0606, 0805, 1206, 1208, 1210, 1616 |
| Compatible Processes | Infrared reflow and JEDEC standards |
Yes, they are compatible with automatic pick-and-place equipment to reduce installation costs.
Yes, the Prism CBI series is RoHS compliant.
