The ASRock 970M Pro3 Motherboard User Manual provides specifications, installation steps, BIOS setup, and software utility instructions.
This manual introduces the ASRock 970M Pro3 motherboard, lists the package contents, and details the board's specifications, layout, and I/O panel. It guides users through CPU, memory, and expansion slot installation, as well as jumper and header configuration.
Subsequent chapters cover software and utility installation, UEFI BIOS configuration, security settings, and troubleshooting. Contact information for technical support is provided at the end of the document.
| Form Factor | Micro ATX |
|---|---|
| CPU Socket | Socket AM3+ |
| Chipset | AMD 970 (Northbridge) / AMD SB950 (Southbridge) |
| Power Phase Design | 4+1 Power Phase |
| SATA Connectors | 6 x SATA3 6.0 Gb/s |
| LAN | Realtek RTL8111E Gigabit Ethernet |
| Audio Codec | Realtek ALC892 |
The package contains the ASRock 970M Pro3 motherboard, a quick installation guide, a support CD, two optional SATA data cables, and an I/O panel shield.
The motherboard provides six SATA3 6.0 Gb/s connectors.
The board supports Socket AM3+ and Socket AM3 processors.
