ASRock H61M-GS / H61M-S Motherboard is a Micro ATX-sized motherboard that supports second-generation Intel® Core™ i7 / i5 / i3 processors, DDR3 1333/1066 memory, and a maximum system capacity of 16GB.
This guide introduces the ASRock H61M-GS and H61M-S micro‑ATX motherboards, describing the package contents, key specifications, and supported CPUs, memory and expansion slots. It also provides detailed information on the board's connectors, jumpers, BIOS settings and environmental compliance.
The manual includes step‑by‑step installation instructions, BIOS configuration tips (e.g., setting Storage Configuration to AHCI for Windows 7/64‑bit), jumper settings for clearing CMOS, and safety warnings about over‑clocking and heat management. Links to driver CDs and the ASRock website are provided for the latest updates. This manual is written in Chinese.
| SATA ports | 4 × SATA2 (3.0 Gb/s) |
|---|---|
| Integrated graphics | Intel HD 2000/3000, max shared memory 1759 MB |
| Audio codec | Realtek ALC662, 5.1 channel |
The integrated graphics can use up to 1759 MB of system memory as shared video memory.
