Technical overview, specifications and selection guide for the AMETEK JOFRA RTC Series dry‑well calibrators.
The AMETEK JOFRA RTC Series dry‑well calibrators provide precise temperature calibration for thermocouples, RTDs, temperature switches and liquid thermometers. The series includes a wide range of models (RTC‑159A, RTC‑159B, … RTC‑700C) covering temperatures from –80 °C up to 1300 °C.
The document contains a selection guide, calibration specifications, software information, and details on accessories such as probes, scanners and portable units. It also describes the dynamic load compensation (DLC) technology that ensures uniform temperature fields and high accuracy during multi‑probe calibrations. This manual is written in Chinese.
| Overall temperature range | -80 °C to 1300 °C |
|---|---|
| RTC‑159A temperature range | -100 °C to 155 °C |
| Maximum simultaneous probes | 24 temperature elements |
| Reference probe outer diameter limit | ≤ 6 mm |
The calibrators cover temperatures from –80 °C up to 1300 °C.
Up to 24 temperature elements can be calibrated simultaneously.
The reference probe must not exceed an outer diameter of 6 mm.
