This document is about SINUMERIK 802D solution line T/M V1.4 general information, including operating and programming manuals, diagnostic manuals, installation and commissioning manuals, and functional descriptions. The document also includes lathe, milling machine, and drive information, as well as information on SINAMICS S120 and SINUMERIK 802D sl T/M data structure.
The manual covers the complete debugging workflow for the SINUMERIK 802D solution line, starting with preparation, hardware checks, and required tools. It explains how to connect the system components, initialize the controller for a specific machine, and configure safety functions.
Detailed sections describe PLC program debugging, drive firmware upgrades and automatic configuration, NC parameter setup, data backup methods (internal, CF‑card, or PC), special functions such as batch debugging, Ethernet features, DP/DP Coupler usage, and the StartUp‑Tool software for drive optimization. This manual is written in Chinese.
| Supported drive family | SINAMICS S120 |
|---|---|
| Supported PLC hardware | S7‑300 |
| Ethernet interface | DP/DP Coupler |
| StartUp‑Tool software | Used for drive automatic optimization |
Special functions, including batch debugging with a CF card, are covered in chapter 8 of the manual.
