This document is a technical manual for SINUMERIK 802D solution line. It mainly introduces the installation and debugging methods of the product, including the connection of the system, system initialization, PLC debugging, drive debugging, NC debugging and so on.
This manual covers the complete setup of the SINUMERIK 802D solution line, including hardware connection, system initialization, PLC programming, drive configuration, and NC parameter tuning. It also details data backup procedures, special functions, and Ethernet communication options.
The document is organized into sections such as Debugging Preparation, System Connection, PLC Debugging, Drive Debugging, NC Debugging, Data Backup, Special Functions, Ethernet Functions, and a PLC Instruction Set, providing step‑by‑step guidance for technicians and end users. This manual is written in Chinese.
| Control Version | SINUMERIK 802D s1 TIM V01020001 |
|---|---|
| I/O Module | PP72/48 |
| Panel Control Unit Part Number | 6FC5303-0AF30-1AAO |
The first step is to correctly connect the system, which is the foundation for successful debugging.
Data can be backed up internally, to a CF card, or to a computer hard drive.
The system supports NC Ethernet functions, driver Ethernet debugging, and PLC Ethernet debugging.
