This document is a diagnostic manual for SINUMERIK 801, SIEMENS SINUMERIK 801 in November 2005. The document provides information on operation and programming, installation and debugging, lathe alarms, etc. It also provides the classification and category of alarm numbers, as well as the corresponding response methods.
This manual explains how to diagnose and resolve abnormal conditions on a machine tool equipped with the SINUMERIK 801 control. It lists alarm numbers, their meanings, and recommended actions for operators and service personnel.
The document is organized into sections covering NCK alarms, cycle alarms, PLC alarms, an instruction table, and a glossary of abbreviations. Version and order‑number information are also included. This manual is written in Chinese.
General alarms are numbered from 000 000 to 009 999.
PLC alarm codes are listed in Table 1‑2 covering 400 000‑499 999 and 700 008‑799 999.
Alarms are arranged in increasing order of alarm number, with gaps between ranges.
The order number is 6FC5598-1CC20-0RP0.
