This manual covers the installation procedure for the metal‑type and touch‑backlit models of the SOYAL access control system, including mounting the controller, connecting power and signal cables, and securing the waterproof strip. It also details wiring standards, such as using AWG‑22‑24 shielded twisted pair for signal lines.
The document explains how to enter edit mode, change passwords, configure card address ranges, set up time‑based access control, and adjust system functions like alarm output and door lock control. Command tables and parameter settings are provided for all supported modes (M4, M6, M8). This manual is written in Chinese.
