The S3C44B0X datasheet describes a microcontroller with six 16‑bit timers that can operate in interrupt or DMA mode. It explains the timer architecture, including prescalers, clock dividers, PWM capabilities, dead‑zone generation and register settings.
The document provides register maps (TCFG0, TCFG1, TCON) and timing formulas, showing how to configure prescalers, dividers and output inversion for precise pulse‑width modulation and output level control. This manual is written in Chinese.
| Number of timers | 6 |
|---|---|
| Timer width | 16‑bit |
| Prescalers | 3 × 8‑bit prescalers, 2 × 5‑bit dividers, 1 × 4‑bit divider |
| PWM capability | Timers 0‑4 have PWM output |
| Clock source frequency | MCLK = 66 MHz |
| Prescaler range | 1‑255 |
The S3C44B0X includes six 16‑bit timers.
Timers 0 through 4 have PWM functionality; timer 5 does not have an external output pin.
