The S3C2410A is a 16/32‑bit ARM920T‑based microcontroller featuring integrated peripherals such as LCD controllers, UARTs, DMA, PWM, ADC, USB, SD/MMC, SPI and I²C. It offers 16 KB instruction cache and 16 KB data cache, an MMU, and supports both STN and TFT LCD displays.
The document contains detailed register tables, pin definitions, electrical characteristics, and operating modes, enabling developers to configure the CPU core, memory interfaces, power modes, and peripheral functions for embedded applications. This manual is written in Chinese.
| Core Voltage | 1.8 V (200 MHz) / 2.0 V (266 MHz) |
|---|---|
| I/O Voltage | 3.3 V |
| Instruction Cache | 16 KB |
| Data Cache | 16 KB |
| Package | 272‑FBGA |
| LCD Maximum Frame Buffer | 4 M pixels |
| ADC Channels | 8 channels, 10‑bit, 500 kSPS |
| PWM Channels | 4 channels, 16‑bit |
| USB Interfaces | 2 host ports, 1 device port |
| UARTs | 3 UART channels |
It uses an ARM920T core.
The S3C2410A‑20 runs up to 200 MHz, while the S3C2410A‑26 runs up to 266 MHz.
The device includes three UART channels.
Typical LCD sizes include 640×480, 320×240, and 160×160, with a maximum frame buffer of 4 M pixels.
