This document is a Chinese datasheet for the S3C2410A processor, which describes the features and characteristics of the processor, including the architecture, system manager, NAND Flash booting, cache memory, clock and power management, interrupt controller, etc.
This Chinese datasheet, compiled by Hangzhou Liyutai Electronics, provides a complete description of the Samsung S3C2410A 16/32‑bit RISC microcontroller. It covers the ARM920T CPU core, internal architecture, system manager, power management, and all on‑chip peripherals such as UARTs, DMA, PWM timers, ADC, LCD controller, USB, SD, SPI, I²C and more.
The document includes extensive register tables, pin‑assignment diagrams for the 272‑FBGA package, electrical characteristics, and operating voltage ranges. It serves as a reference for hardware designers and firmware developers who need precise information on register addresses, bit fields, and timing requirements. This manual is written in Chinese.
| CPU core | ARM920T |
|---|---|
| Maximum operating frequency | 266 MHz |
| Core voltage | 1.8 V |
| I/O and memory voltage | 3.3 V |
| Package | 272‑FBGA |
| General‑purpose I/O pins | 117 |
| UART channels | 3 |
| DMA channels | 4 |
| PWM timers | 4 (16‑bit) |
| ADC channels | 8 (10‑bit) |
| USB host ports | 2 |
| USB device ports | 1 |
| I²C bus channels | 1 (multi‑master) |
It uses an ARM920T core.
The device provides 117 general‑purpose I/O pins.
The highest supported frequency is 266 MHz (S3C2410A‑26 version).
