This manual introduces the hardware design of ARMSYS6410 development board, including system architecture, optional information, structure and size, core board, expansion board, hardware details, system startup and configuration instructions, etc.
The ARMSYS6410 is a development board based on the Samsung S3C6410 (ARM1176JZF‑S core) processor, offering low power consumption and a rich set of peripherals. It supports LCD, TVout, camera, multiple serial ports, USB OTG/Host, Ethernet, IDE, CF, SD and MMC interfaces, making it suitable for embedded applications such as handheld devices, industrial controllers, and multimedia terminals.
The manual details hardware dimensions, front‑panel layout, interface pin‑outs, supported operating systems (WINCE 6.0, Linux 2.6, Ubuntu, Android), storage options, available LCD modules, and warranty and technical support policies. This manual is written in Chinese.
| DDR SDRAM Frequency | 266 MHz |
|---|---|
| USB Interfaces | USB2.0 OTG and USB Host |
| Supported OS | WINCE 6.0, Linux 2.6, Ubuntu, Android |
Yes, version 1.1 added Linux support information.
