Application Note AN10121 introduces ten golden rules for the successful application of thyristors and triacs.
The document introduces thyratrons (闸流管) and bidirectional thyristors (双向可控硅) and presents ten practical rules covering conduction, switching, gate‑drive design, noise mitigation, voltage‑rate limits, and thermal management. It also includes device specifications, package options, and mounting guidelines.
Detailed sections describe how to select appropriate gate current, avoid false triggering, design RC buffers, use inductors or MOVs for over‑voltage protection, and calculate heatsink requirements. Practical mounting methods such as clamp pressure, bolt fixation, and cautions against riveting are also covered. This manual is written in Chinese.
