This document is about the fax machines models KX-FP716CN-B, KX-FP716CN-W, KX-FP719CN-B, and KX-FP719CN-W from Panasonic Communication Systems Co., Ltd. The document includes information on safety precautions, warnings, technical specifications, features, and technical explanations.
This manual provides detailed safety guidelines for technicians repairing the Panasonic KX‑FP716CN and KX‑FP719CN fax machines, including warnings about electrical shock, static discharge, and the use of manufacturer‑specified replacement parts. It also explains the handling of lead‑free (PbF) solder and battery replacement procedures.
The document contains a full table of contents covering safety matters, technical specifications, wiring diagrams, block diagrams, control circuitry, memory allocation, and step‑by‑step disassembly and re‑assembly instructions for each major sub‑assembly, as well as a comprehensive parts list and troubleshooting information. This manual is written in Chinese.
The AC power cord must be disconnected to prevent electric shock.
The device uses a CR2032 lithium battery.
