SMS0528 is a digital pen segment LCD display module that can display 5 digits and 4 Chinese characters. It uses a two-wire serial interface and is suitable for applications such as smart gas meters.
About this manual
The SMS0528 is a digital LCD display module designed for smart meters and similar applications. It can display five numeric digits, four segment characters and one decimal point using a reflective LCD.
Key specifications include a 2.7‑5.5 V operating voltage, less than 10 µA current at 5 V, 120° viewing angle, and a two‑wire serial interface. The module measures 13.8 mm and operates from –10 °C to +50 °C. This manual is written in Chinese.
What's inside
- Overview
- Technical Specifications
- Interface Signals
- Physical Dimensions
- Pin Mapping
