长沙太阳人电子 Manuals

Key facts

Manuals: 103
Languages: ZH
Last added: 2012-03-15

Featured 长沙太阳人电子 manuals

Sunman SMG12864K5 Display Module User Manual

User Manual 3 pages · 38 KB · ZH

The SMG12864K5 is a standard dot‑matrix LCD display module with a 128 × 64 pixel resolution and 0.46 × 0.46 mm dot size. It incorporates an NT7532 LCD controller and can be directly connected to an MCU for a variety of instrument and electronic device applications.

The manual provides the module’s pin‑out (SI, SCL, A0, /RES, /CS, VDD, VSS, BG), power requirements (3.6‑5.2 V, 700 µA typical, 15 mA max) and the configuration registers needed to set LCD bias, ADC select, COM voltage and display mode. Wiring diagrams and example connections to an 8051 MCU are also included. This manual is written in Chinese.

Covers: Features · Interface Definition · Parameters · Display Modes · Configuration Registers · Power Supply

Sunman SMG16032D LCD Display User Manual

User Manual 9 pages · 77 KB · ZH

This manual describes the SMG16032D dot‑matrix LCD module produced by Sunman Electronics. It covers the module’s physical dimensions, electrical characteristics, and supported interface modes (parallel and serial). Detailed connection diagrams for 8051‑series microcontrollers are included, along with default factory settings.

The document also lists all command codes, timing diagrams, and procedures for controlling the display, such as clearing the screen, setting cursor position, and using graphic RAM. Technical parameters like display capacity, dot size, operating voltage, temperature ranges, and current consumption are provided for designers and technicians. This manual is written in Chinese.

Covers: Module Overview · Interface Signal Description · Physical Dimensions · Technical Parameters · Connection Reference · Command Tables

Sunman SMG240128A Liquid Crystal Display Module Manual

User Manual 6 pages · 73 KB · ZH

The SMG240128A is a dot‑matrix LCD module with a 240 × 128 pixel resolution and 0.45 × 0.45 mm dot size. It uses a T6963C compatible controller and operates from a 4.8‑5.2 V supply with a backlight driven at 5 V.

This manual describes the module’s technical parameters, pin‑out and signal definitions, RAM mapping, initialization sequence, command formats, data write/read procedures and timing characteristics. Reference circuits for 8051‑based hosts are also included. This manual is written in Chinese.

Covers: Overview · Technical Parameters · Interface Signal Description · Physical Dimensions · Controller Interface · RAM Mapping

Sunman Electronics SMC1602C LCD Module User Manual

User Manual 5 pages · 68 KB · ZH

The SMC1602C is a 16‑character, 4.95 × 7.95 mm LCD module that includes an internal HD44780‑compatible controller. It operates from a 4.8‑5.2 V supply and features a yellow‑green backlight.

The manual provides detailed pin‑out information, physical dimensions, initialization sequences, data handling procedures, and timing diagrams for proper integration with 8051‑type microcontrollers. This manual is written in Chinese.

Covers: Overview · Technical specifications · Interface pin description · Physical dimensions · Initialization procedure · Data control

Latest 长沙太阳人电子 manuals

Sunman SMG12864K5 Display Module User Manual
User Manual 3 pages · 38 KB · ZH
The Sunman SMG12864K5 manual details specifications, wiring and configuration for the 128×64 STN LCD display module.
Changsha Sunman Electronics SMG12864D3 Manual
Sunman SMG16032D LCD Display User Manual
User Manual 9 pages · 77 KB · ZH
The Sunman SMG16032D LCD display user manual provides specifications, connection methods, command tables, and operation instructions.
Changsha Sunman Electronics smg12864sl Manual
Sunman SMG240128A Liquid Crystal Display Module Manual
User Manual 6 pages · 73 KB · ZH
The Sunman SMG240128A LCD module manual provides specifications, interface details, command set and operation instructions.
Sunman Electronics SMC1602C LCD Module User Manual
User Manual 5 pages · 68 KB · ZH
User manual for the Sunman Electronics SMC1602C 16‑character LCD module with specifications, wiring and initialization instructions.
Sunman Electronics SMC2002A LCD Module User Manual
User Manual 5 pages · 50 KB · ZH
User manual for the Sunman Electronics SMC2002A LCD module, covering specifications, wiring, and operation procedures.
Changsha Sunman Electronics SMC0802B liquid crystal display module Manual
User Manual 5 pages · 55 KB · ZH
The Changsha Sunman Electronics SMO0802B LCD module user manual provides overview, specifications, pin connections, and operation instructions.
Sunman Electronics SMC1604A LCD Module User Manual
User Manual 5 pages · 61 KB · ZH
The Sunman Electronics SMC1604A LCD module user manual provides specifications, pinout, initialization procedures, and interface timing details.
Changsha Sunman Electronics SMC1601C LCD Module User Manual
User Manual 5 pages · 98 KB · ZH
The Changsha Sunman Electronics SMC1601C LCD module user manual provides specifications, interface details, and operation instructions.
Sunman Electronics SMC2004A Liquid Crystal Display Module Manual
User Manual 5 pages · 98 KB · ZH
The Sunman SMC2004A LCD module manual provides specifications, interface details, and operation instructions for the display.
Sunman SMC1601SA LCD Module User Manual
User Manual 4 pages · 72 KB · ZH
The Sunman SMC1601SA LCD module user manual provides specifications, interface details, timing diagrams, and command instructions for the three‑wire serial…
Sunman SMC1602B LCD Module User Manual
User Manual 5 pages · 80 KB · ZH
The Sunman SMC1602B LCD Module User Manual provides specifications, pinout, command set, and operation instructions for the 16‑character dot‑matrix display.
Sunman SMC1602E LCD Display Module User Manual
User Manual 5 pages · 67 KB · ZH
The Sunman SMC1602E LCD display module manual provides specifications, pinout, initialization sequence, and operating instructions.
Changsha Sunman Electronics SMC2002A Manual
