This is a projector user manual, which contains the projector's features and characteristics, installation methods, power connection, signal source connection and other contents.
The InFocus Proxima C130 is a digital projector designed for both business presentations and home video use. This manual provides step‑by‑step instructions for safe installation, proper placement, and connecting computers or video sources.
Key sections cover connector panels, image size calculations, lamp maintenance, and troubleshooting red‑LED error codes. Safety warnings, FCC/CE compliance information, and optional accessories are also included. This manual is written in Chinese.
| Maximum supported resolution | 1280 × 1024 |
|---|---|
| 12 V DC output | Available via 3.5 mm trigger |
The filter should be cleaned every 250 hours of operation to keep the lamp temperature low and extend lamp life.
A flashing red LED signals an error; for example, one flash means the lamp did not ignite, while other patterns indicate lamp timer expiration, fan failure, or overheating.
Yes, the manual advises using an approved ceiling mount and refers to the installation instructions for ceiling mounting.
The projector provides three computer/video options: M1, Super Video, and a mixed RCA audio/video connector, plus separate audio output and 12 V DC output.
