Danfoss VLT is the world's leading brand of AC frequency converters. Since its inception in 1968, it has been renowned for its high quality, quality service and high cost-effective products. Danfoss VLT series frequency converters have a wide range of applications and are widely used in fans, pumps, compressors and other industrial equipment, which can bring customers significant energy saving, environmental protection, efficiency and other advantages.
The VLT FC101 is a variable‑frequency drive covering a power range of 0.25‑90 kW and input voltages from 200‑480 V. It is designed for HVAC and water‑pump systems, offering integrated control functions, safety features, and optional IP protection levels.
This document includes product overviews, technical specifications, wiring diagrams, installation procedures, safety guidelines, and configuration parameters such as motor speed limits, ramp times, and communication interfaces. This manual is written in Chinese.
| Power rating | 0.25‑90 kW |
|---|---|
| Input voltage | 200‑240 V ±10 % / 380‑480 V ±10 % |
| Output frequency range | 0‑400 Hz |
| Weight | 3.3 kg |
The FC101 covers a power range of 0.25 kW to 90 kW.
It can be powered from 200‑240 V (±10 %) or 380‑480 V (±10 %).
The unit weighs about 3.3 kg.
