This manual describes the installation, operation and programming of the Danfoss VLT HVAC drives. The manual contains information on safety instructions, mechanical installation, electrical connection, operation, programming and troubleshooting.
The VLT HVAC Drive User Manual provides detailed guidance on safely installing, wiring, and operating the drive. It includes safety warnings, mechanical and electrical installation steps, and instructions for connecting and testing the motor.
The manual also describes programming options, parameter lists, troubleshooting alerts, and technical specifications such as power ratings, input voltage ranges, and grounding requirements. This manual is written in Chinese.
| Power rating (high end) | 11‑75 kW |
|---|---|
| Power rating (low end) | 11‑30 kW |
| Input voltage (low voltage) | 200‑240 VAC |
| Input voltage (high voltage) | 380‑480 VAC |
| Minimum grounding cable cross‑section | ≥ 10 mm² |
| Leakage current threshold | > 3.5 mA |
For a 11‑75 kW unit wait 4 minutes; for a 11‑30 kW unit wait 15 minutes before servicing.
The safety‑stop function, defined by EN 954‑1 category 3, stops the drive safely and is activated by pressing the OFF button after ensuring the drive is disconnected from the main power.
The grounding cable must have a cross‑section of at least 10 mm² to ensure a reliable mechanical connection.
A leakage current greater than 3.5 mA will trigger an alarm.
