This document contains technical specifications, connection methods, user instructions, maintenance modes, and troubleshooting for Philips color televisions. It also includes detailed information such as circuit diagrams, circuit layouts, and PWB layouts.
This manual covers the technical specifications, connection diagrams and chassis layout of the Philips SK3.0A CA colour television. It includes safety instructions, recommended tools, and guidelines for handling high‑voltage components such as the CRT.
Detailed sections describe how to disassemble the rear and side panels, locate repair points, replace faulty modules, and re‑assemble the set. Fault codes, troubleshooting procedures and a spare‑parts list are also provided. This manual is written in Chinese.
| Display type | CRT |
|---|---|
| Screen size | 29" (72 cm) |
| Colour system | PAL D/K, SECAM DMK |
| Audio system | FM‑stereo |
| Supply voltage | 160‑260 V AC |
| Frequency | 50‑60 Hz |
| Operating temperature | -5 to +45 °C |
| Maximum humidity | 90% RH |
| Power consumption (normal) | 80 W |
Use an isolation transformer to connect the TV to the AC line, replace safety‑related components with identical parts, wear eye protection when handling the CRT, and ensure proper grounding before work.
The TV consumes about 80 W during normal operation and about 9 W in standby mode.
The screen measures 29 inches (approximately 72 cm) diagonally.
