Maxtor DiamondMax 1750 AT Hard Disk Drive Installation Manual

This manual provides technical information regarding the installation and use of the Maxtor DiamondMax™ 1750 AT hard disk drives.

Brand: Maxtor
Category: Hard disk
Document type: User Manual
Language: English
Pages: 62
File format: PDF
File size: 1.4 MB
Published: 16 October, 2023
Updated: 16 October, 2023
Model: DiamondMax™ 1750
MD5 checksum: 92ACD2F4D020E72C5B366E959C8E2B36
PDF: Maxtor DiamondMax 1750 AT Hard Disk Drive Installation Manual PDF

About this manual

This manual provides technical information for OEM engineers and systems integrators regarding the installation and use of Maxtor DiamondMax™ 1750 AT hard disk drives. It covers various models including the 87000D8, 86480D8, 85250D6, 84320D5, 83500D4, 83240D4, 82560D3, and 81750D2. The document includes instructions for unpacking, handling precautions, physical installation, and system setup.

What's inside

Introduction
Product Description
Product Specifications
Handling and Installation
AT Interface Description
Host Software Interface
Interface Commands
Service and Support

Specifications

Interface	AT Attachment
Ultra DMA Mode	UltraDMA - Mode 2
Cylinder Limitation	4092

Frequently asked questions

What precautions should be taken before unpacking the drive?

Review Sections 1 through 4 and take proper electro-static discharge (ESD) precautions, including personnel and equipment grounding.

Where should a drive be stored if not immediately installed?

Store the drive on a padded, grounded, antistatic surface.

Can the drive be powered up by plugging a live DC source cable into the connector?

No, you must never switch DC power onto the drive by plugging an electrically live DC source cable into the drive's connector.
