EDP-CM-LPC2368 CPU Module is a Command Module designed by Electrocomponents plc to support NXP range or ARM/Cortex MCU’s. It can accommodate four different device types: LPC2368 (ARM7), LPC1768 (Cortex M3), LPC1343 (Cortex M3) and LPC1113 (Cortex M0). Each of the boards come with its own suite of software to fully exercise the RS-EDP Application Modules and the peripherals available on the MCU device.
The EDP-CM-LPC2368 Command Module is designed for the RS-EDP platform to support NXP range or ARM/Cortex microcontrollers, specifically the LPC2368 (ARM 7). The module maps the I/O of the MCU on the board to the backplane of the RS-EDP system, accommodating various device types including the LPC1768, LPC1343, and LPC1113.
| Supported MCU | LPC2368 (ARM 7), LPC1768 (Cortex M3), LPC1343 (Cortex M3), LPC1113 (Cortex M0) |
|---|---|
| Voltage | 3.3V |
| Clock | 32KHz |
It supports the LPC2368, LPC1768, LPC1343, and LPC1113.
The module uses a 3.3V microprocessor and the I/O is mostly 3.3V.
