Featured Electrocomponents manuals
Electrocomponents RS-EDP System EDP Module Developers Manual
This manual provides instructions for developers creating modules to fit into the RS-EDP platform. It details the design considerations for both CPU Modules (CM) and Application Modules (AM), covering operating voltages, grounding arrangements, analogue references, reset management, battery backup, and various communication interfaces including UART, CAN, I2C, SPI, Ethernet, and USB.
Covers: Introduction · Designing a CPU Module · Design Considerations for CPU Modules · Operating Voltage and Vcc_CM selection · Grounding Arrangement · Analogue Voltage Reference
Electrocomponents RS-EDP-CM-mbed Adapter Board User Manual
The RS-EDP-CM-mbed adapter module is designed to connect the mbed development module to the RS-EDP platform. It acts as the Command Module (CM) for the system, dictating the voltage level (3.3V) and remapping the mbed's I/O pins to the RS-EDP backplane. The board allows users to utilize the mbed module's ARM7-based microprocessor within the RS-EDP system without requiring a full C compiler installation on the host machine.
The adapter board features several additional interfaces beyond simple pin remapping. It includes a mini SD Card interface and an SPI serial connection for a small graphics LCD. The board also provides extensive link options and solder jumpers to configure various signal mappings, including support for analogue, digital I/O, communications, and motor drive modules.
Covers: Introduction · Pin Mapping · MCU Pin Allocation · Backplane Resources · Solder Link Options · Zero Ohm Links
Electrocomponents EDP-CM-LPC1113 CPU Module User Manual
This manual covers the Electrocomponents EDP-CM-LPC1113 CPU Module, which is designed to utilize the NXP LPC1113 (Cortex-M0) microcontroller within the RS-EDP platform. The module maps the I/O of the MCU to the backplane of the RS-EDP system, supporting various application modules and peripherals.
Covers: Introduction · Pin Allocation · Resources Used/Available · Solder Link Options · Zero Ohm Links · Software Support
Electrocomponents EDP-CM-LPC2368 Command Module User Manual
The EDP-CM-LPC2368 Command Module is designed for the RS-EDP platform to support NXP range or ARM/Cortex microcontrollers, specifically the LPC2368 (ARM 7). The module maps the I/O of the MCU on the board to the backplane of the RS-EDP system, accommodating various device types including the LPC1768, LPC1343, and LPC1113.
Covers: Introduction · MCU Mapping · MCU Pin Allocation · Resources Used/Available · Alphabetical Listing of MCU pins · Backplane Signal Names and Connections
Latest Electrocomponents manuals
Electrocomponents RS-EDP System EDP Module Developers Manual
Programming Manual 33 pages · 1.3 MB · ENDeveloper guide for designing CPU and Application modules compatible with the Electrocomponents RS-EDP system platform.
Electrocomponents RS-EDP-CM-mbed Adapter Board User Manual
User Manual 21 pages · 1 MB · ENThis manual describes the Electrocomponents RS-EDP-CM-mbed adapter board, which remaps the mbed module pinout to the RS-EDP platform and includes SD card…
Electrocomponents EDP-CM-LPC1113 CPU Module User Manual
User Manual 25 pages · 2 MB · ENUser manual for the Electrocomponents EDP-CM-LPC1113 CPU Module, detailing pin allocation, solder link options, and software support for the NXP LPC1113…
Electrocomponents EDP-CM-LPC2368 Command Module User Manual
User Manual 28 pages · 929 KB · ENUser manual for the Electrocomponents EDP-CM-LPC2368 Command Module, detailing MCU mapping, solder link options, and software support for the RS-EDP platform.
Electrocomponents EDP-CM-STR9 CPU Module User Manual
User Manual 30 pages · 1.6 MB · ENThis manual covers the EDP-CM-STR9 CPU module, an ARM9 development platform featuring 96MHz processing, USB-JTAG debugging, and Ethernet capabilities.
Electrocomponents EDP System and Baseboard User Manual
User Manual 35 pages · 4.5 MB · ENThis manual covers the structure and features of the basic EDP system, including user instructions for the two-slot and four-slot baseboards.
Electrocomponents EDP-CM-LPC1343 Command Module User Manual
User Manual 25 pages · 2 MB · ENUser manual for the Electrocomponents EDP-CM-LPC1343 Command Module, covering pin allocation, solder link options, and software support.
Electrocomponents EDP-AM-MC1 DC Brushed Motor Controller Application Module Manual
User Manual 15 pages · 1.4 MB · ENThis manual covers the hardware configuration, control modes, protection features, and connection methods for the EDP-AM-MC1 DC brushed motor controller module.
Electrocomponents EDP-AM-CO1 Communications Module User Manual
User Manual 12 pages · 1.1 MB · ENUser manual for the EDP-AM-CO1 communications IO module, detailing interfaces for CAN, RS232, RS485, and USB, along with jumper configurations and software…
Electrocomponents EDP-AM-AN16 Analog Input Module User Manual
User Manual 14 pages · 1.8 MB · ENThis manual covers the EDP-AM-AN16 analog input module for the RS EDP system, detailing anti-aliasing filters, jumper settings, software drivers, and input…
Which document do I need?
Programming Manual
Instruction set, parameters and examples for configuring or programming the device.
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Electrocomponents manuals
What operating voltages are supported on the RS-EDP platform?
There are currently two voltages supported on the platform, a 5.0V one and a 3.3V one.
From: Electrocomponents RS-EDP System EDP Module Developers Manual
How is the system operating voltage determined?
The 'Command Module' dictates whether the whole system is a 3.3V one or a 5.0V one.
From: Electrocomponents RS-EDP System EDP Module Developers Manual
What is the function of the RS-EDP-CM-mbed adapter module?
It is designed to remap the pin out of the mbed module to that of the RS-EDP platform.
From: Electrocomponents RS-EDP-CM-mbed Adapter Board User Manual
Does the adapter board support SD cards?
Yes, it includes a mini SD Card interface.
From: Electrocomponents RS-EDP-CM-mbed Adapter Board User Manual
What microcontroller does the EDP-CM-LPC1113 use?
It uses the NXP LPC1113 Cortex-M0 microcontroller.
From: Electrocomponents EDP-CM-LPC1113 CPU Module User Manual
What is the operating voltage of the module?
The module uses a 3.3V microprocessor and mostly 3.3V I/O.
From: Electrocomponents EDP-CM-LPC1113 CPU Module User Manual
