This manual covers the Mitsubishi FX2N-2AD programmable logic controller module. It includes detailed specifications, power requirements, communication interfaces, and pin assignments for proper installation and maintenance.
The document provides wiring diagrams, RS232C interface details, supported baud rates, and troubleshooting guidance to help technicians service and configure the module safely and efficiently.
| Supply Voltage | 24V DC |
|---|---|
| Supply Voltage Tolerance | ±10% |
| Maximum Input Current | <190 mA |
| Maximum Output Current | <300 mA |
| Supported Baud Rates | 300‑19200 bps |
The module requires a 24 V DC supply.
It supports baud rates of 300, 600, 1200, 2400, 4800, 9600 and 19200 bps.
The maximum input current is less than 190 mA.
