The ANTEC AY series is a compact public address system that integrates a broadcast amplifier, MP3 decoder, digital tuner, and zone control. It supports MP3, FM, and AM playback, offers up to six zone outputs, and provides programmable scheduling for automatic operation in environments such as residential complexes, supermarkets, and hotels.
The manual explains safety precautions, hardware connections, key functions, operation procedures for MP3 and radio playback, zone control, programming of schedules, and troubleshooting steps. It also includes technical specifications, dimensions, and warranty information. This manual is written in Chinese.
| Output Power | 60W‑6500W (model dependent) |
|---|---|
| Supported Audio Sources | MP3, FM, AM, AUX, line‑in |
| Zone Outputs | 6 zones, 100 V constant‑voltage output per zone |
| Dimensions (W×H×D) | 485 mm × 410 mm × 90 mm |
| Weight | 12 kg‑20.5 kg (model dependent) |
| Power Supply | AC 220‑240 V, 50‑60 Hz |
| Frequency Response (Microphone Input) | 60 Hz‑18 kHz |
| Maximum Fuse Rating | 10 A |
