Antec's latest product, the P193 chassis, combines the famous cooling technology and quiet technology of the Performance One series, and has been improved to accommodate more large-sized accessories. It features a dual-layer design, noise reduction, multiple drive slots, and a cooling system. In addition, the P193 also has new features such as a front door frame full of ventilation, integrated filter and door design, ventilated drive box cover, and a forward-shifted bottom space.
The P193 chassis features a dual‑layer construction that isolates the power supply to reduce heat and noise. It offers a large interior that can accommodate many high‑end components, with a ventilated front door frame and integrated filters for improved airflow.
Cooling is provided by a rear 120 mm fan, two top 140 mm fans, a bottom 120 mm fan, and a side 200 mm fan as standard, with optional front and middle 120 mm fans. The case supports Mini‑ITX, micro‑ATX, ATX and extended ATX motherboards, provides multiple drive bays, and includes front USB 2.0, eSATA and audio ports. This manual is written in Chinese.
| Drive bays | 4 × 5.25" external, 1 × 3.5" external, 6 × 3.5" internal |
|---|---|
| Standard fans | Rear 120 mm, Top 2 × 140 mm, Bottom 120 mm, Side 200 mm |
| Dimensions (H × W × D) | 20.25" × 8.1" × 23.25" (extra 9.5" width due to side fan) |
| Weight | Net 35.8 lb (16.25 kg), Gross 41.7 lb (18.9 kg) |
| Supported motherboards | Mini‑ITX, micro‑ATX, ATX, extended ATX |
| Front ports | 2 × USB 2.0, 1 × eSATA, audio I/O (AC97/HAD compatible) |
It offers four external 5.25" bays, one external 3.5" bay, and six internal 3.5" bays.
Standard fans are a rear 120 mm, two top 140 mm, a bottom 120 mm, and a side 200 mm fan; optional front and middle 120 mm fans can be added.
The case measures 20.25" × 8.1" × 23.25" (extra 9.5" width due to side fan) and weighs 35.8 lb net (41.7 lb gross).
